Mini unique mould wifi diagnostic scanner knonnwei KW901 can be
compatible Android and IOS system
| Item mould | KW901 Wifi |
| Brand | Konnwei |
| Application | Detect all 12V OBD II gasoline and diesel cars after 1996 |
| System | Android and IOS |
| Feature | Android is free torque,IOS is unfree dashcommand |
| Support protocol | ISO 9141, KWP2000, SAE J1850, CAN,J1850 VPW,J1850 PWM |
| Language | English is default language,you could select the language what you
need on phone setting interface |
| Material | ABS |
| Warranty | 24 months worry free |
| Color | (1)Black write (2) White red (3) Black red (4) Black orange (5) Red
(6) Black |
Features of Mini unique mould wifi diagnostic scanner knonnwei KW901 can be
compatible Android and IOS system:
- KW901 able to detect and interpret these protocols automatically.
- It also provides support for high speed communications and a low
power sleep mode.
- It use AT commands to communicate with a host device (For PC, For
notebook, For iPhone,For iPod touch, For iPad and so on).
- There are plenty of software packages available, which are fully
compatible with KW901.
Some of them have pretty useful features, such as engine running
parameters monitoring, DTC reading and clearing, MPG meter, etc.
- You can even write your own software on a specified hardware
platform if you wish, because the AT commands are fully documented
and very well explained.
KW901 measuring only 2.7 x 1.25x 0.9 inches, and it comes attached
with a 6 ft OBDII cable for easy installation.
- It also comes included with a power switch built-in to prevent the
need for having to constantly disconnect your unit from the OBDII
port.
- It is compatible with 1996 and later vehicles.
- Connecting to your iPhone / iPod touch is made by WIFI connection
in adHoc mode.
With proper software installed in the host device, you may have
following parameters read out from your vehicle:
- Vehicle Speed
- RPM
- Fuel Consumption*
- Engine Coolant Temp
- Fuel Pressure
- Calculated Engine Load
- Throttle Position
- Intake Manifold Pressure
- Air Intake Temp
- Timing Advance
- Mass Air Flow
- Fuel Level
- Barometric Pressure
- EVAP System Vapor Pressure
- Fuel Trim
Specifications of Mini unique mould wifi diagnostic scanner knonnwei KW901 can be
compatible Android and IOS system:
Range: 50 ft (Line of sight)
Antenna: Internal
Power Consumption: 0.75 Watts (With Power Switch)
Wifi Standard: 802.11a/b/g
Operating Temperature: -15 to 100 Deg Celsius
Plastic: Automotive Grade
Dimensions: 2.75 x 1.25 x 1.2 inches
Connection Type: Wifi
Mini unique mould wifi diagnostic scanner knonnwei KW901 can be
compatible Android and IOS system Languages & Support Protocol:
Can use phone to select the language you need
Support Protocol: I9141, KWP2000, SAE J1850, CAN,J1850 VPW,J1850
PWM
Package includes:
1x KW901 WIFI Scanner
1x Software CD
1x English User Manual
