Why choose KW210 battery tester as your scnner tool?
Key functions & features:
1. System voltage: 12 Volts
2. Test Result: Good, Recharge or Replace
3. Capacity - Cold Cranking Amps (CCA), DIN, EN and IEC information
relative to battery rating.
4. Internal resistance value (mΩ)
5. Life in percentage (%)
6. Cranking system
7. Charging system
8 . Record and re-play battery data, Life-time free update service
9. Battery test, cranking test, charging test and other additional
functions.
[DATA READINGS]
The KONNWEI KW210 12V car battery tester is able to effectively analyze and read
important car data such as voltage, internal resistance, cold
cranking amp and AH capacity, battery health and charge status.
[ACCURATE MEASUREMENTS]
This professional automotive battery tester provides accurate
results, calculates the cold cranking capability of the battery and
the aging extent, allowing for a quicker, more precise car
repairing.
[WIDELY COMPATIBLE]
Beginner or expert, this car battery diagnostic tester can be used
with a wide selection of 12V 100-2000 CCA regular flooded
batteries, AGM flat plate, AGM spiral, as well as GEL batteries.
[EXTRA FEATURES]
The KW210 car battery tester displays test results in text and
graphing, displaying the real-time battery voltage in a waveform.
With an intelligent 2.4” LCD screen and STM-32 main chip, reading access is practical and
rapid! Lifetime update service is supported by KONNWEI BTlink app
Applications
1. Measure Standard
2. CCA:100-2000
3. BCI:100-2000
4. CA:100-2000
5. MCA:100-2000
6. JIS:26A17-24SH52
7. DIN:100-1400
8. IEC:100-1400
9. EN:100-2000
10 SAE:100-2000
11. GB:100-1400
12 Display: Color TFT LCD Screen
13. ystem Voltage:12 Volts
14. Input Voltage Range:8V-16V
15. Power Requirements: No internal batteries required.
16. Power on when hooked up during testing.
17. Operating Temperature:0℃-50℃
18. Storage Temperature:-20℃-70℃
19. Weight:0.4Kg
Support language: English, French, Spanish German, Russian,
Italian, Portuguese,Dutch
Application:
Use a test a wide range of 12v batteries(Starting{SLI},Deep Cycled
and Marine) of Wet(Flooded),VRLA or Maintenance Free (MF),Sealed
Maintenance Free (SMF), Absorption Glass Mat(AGM),EFB and GEL Cell.
The major battery standards CA,CCA,BCL,MCA,JIS,SAE,EN,GB,DIN and
IEC are supported.
Package includes:
1*KONNWEI KW210 Auto Diagnostic Scanner
1*Mini USB cable
1*User’s Manual
Item size( cm):12.7*7.8*2.0
package size (cm):18.3*5.3*15.2
Item Net weight(kgs):0.34kg
Package Gross weight(Kg):0.38kg
qty/cn : 50pcs/cn
Carton size : 49*39*51CM,
Carton Weight : 19.85KG/carton
