    KONNWEI KW600 car battery analyzer all 8-16V car support major battery standards free print and upgrade via PC

    Ask Lasest Price
    Brand Name : Konnwei
    Model Number : KW600
    Certification : Patent, CE, RoHS, FCC
    Price : Negotiable
    Payment Terms : T/T, Western Union, MoneyGram, Visa, Paypal, L/C, D/A, D/P
    Supply Ability : 50,000pcs obd2 scanner codes per month
    Delivery Time : for samples, stocks are available; 5000pcs obd2 scanner codes in a week
    • Product Details
    • Company Profile

    KONNWEI KW600 car battery analyzer all 8-16V car support major battery standards free print and upgrade via PC

    KONNWEI KW600 Auto Battery tester all 8-16V car support major battery standards free print and upgrade via PC

    Product Name: KW600

    KONNWEI KW600 12V car battery tester can analyze and read important car data voltage, internal resistance, cold cranking amp and AH capacity, battery health and charge status.

    then provides accurate results, calculates the cold cranking capability of the battery and the aging extent,Test results display in both text and graphing, but the real-time battery voltage showing in a waveform.

    With an intelligent 2.4” LCD screen and STM-32 main chip, reading access is practical and rapid! Lifetime update service is supported by KONNWEI BTlink app ,support selected data via PC.


    KW600 Prints out data to PC

    1. After install the "uplink" program on PC, connect the scanner to PC with USB cable. (No need to press any buttons).

    2. Launch the program"uplink" , Select "Print" option.

    3. Operation on scanner: go to main menu, select " Print Data" ; Select the data option that you want to print to PC,

    4. After select the "print data", the data stream that storaged in the scanner will be sent to PC software, you may modify them before printing them out from PC's printer.


    Key Parameter:

    Produce NameKONNWEI KW600
    Item TypeDiagnostic Tools Battery analyzer
    IC chipSMT32F103C8T6
    Function1Display real - time battery performance
    ApplicationAlpplicable for 8-16V Vehicle,major battery standards
    Feature1Lifetime upgrade free and print data on PC
    Feature2Factory direct sales cheap and high quality
    Display2.4 inch LCD screen
    Language

    Chinese, English, German, French ,Japanese,Korean, Dutch, Russian, Spanish,italian , Portuguese , Polish

    Warranty1 year

    KW600 battery tester key functions & features:

    1.System voltage: 6V 12 Volts,Input Voltage Range:8V-16V

    2.Test Result: Good, Recharge or Replace

    3.Capacity ,Cold Cranking Amps (CCA), DIN, EN IEC information relative to battery rating.

    4.Internal resistance value (mΩ)

    5.Life in percentage (%)

    6.Cranking system

    7.Charging system

    8.Voltage test in waveform

    9.Record and re-play battery data, Life-time free update service

    10.Battery test, cranking test, charging test and other additional functions.

    11.Measure Standard

    CCA 100-2000 ,BCI 100-2000 ,CA 100-2000 ,MCA 100-2000,

    JIS 26A17-24SH52 ,DIN 100-1400 ,IEC 100-1400 ,EN 100-2000 ,SAE 100-2000,

    GB 100-1400,


    Package includes:

    1*KONNWEI KW600 Auto Diagnostic Scanner

    1*Mini USB cable

    1*User’s Manual
