KONNWEI KW901 WIFI ELM327 Mini OBD2 Auto Diagnostic Scanner Tool for Android/IOS

KW901 WIFI Description:

With proper software installed in the host device, you may have following parameters read out from your vehicle:

• Vehicle Speed
• RPM
• Fuel Consumption*
• Engine Coolant Temp
• Fuel Pressure
• Calculated Engine Load
• Throttle Position
• Intake Manifold Pressure
• Air Intake Temp
• Timing Advance
• Mass Air Flow
• Fuel Level
• Barometric Pressure
• EVAP System Vapor Pressure
• Fuel Trim

Parameter:

KW901 WIFI functions & features:

1.KW901 able to detect and interpret these protocols automatically.

2.It also provides support for high speed communications and a low power sleep mode.

3.It uses AT commands to communicate with a host device (PC, notebook, iPhone, iPod touch, iPad and so on).

4.There are plenty of software packages available, which are fully compatible with KW901.

5.Some of them have pretty useful features, such as engine running parameters monitoring, DTC reading and clearing, MPG meter, etc.

6.Connecting to your iPhone / iPod touch is made by WIFI connection in adHoc mode..

7.It also comes included with a power switch built-in to prevent the need for having to constantly disconnect your unit from the OBDII port.

8.It is compatible with 1996 and later vehicles.

9. you can even write your own software on a specified hardware platform if you wish, because the AT commands are fully documented and very well explained.

and it comes attached with a 6 ft OBDII cable for easy installation.

Support agreements and languages:

1.ISO 9141, KWP2000, SAE J1850, CAN,J1850 VPW,J1850 PWM

2.The default is English. But U can use phone to select the language u need

Specifications:

1.Range: 50 ft (Line of sight)

2.Antenna: Internal

3.Power Consumption: 0.75 Watts (With Power Switch)

4.Wifi Standard: 802.11a/b/g

5.Operating Temperature: -15 to 100 Deg Celsius

6.Plastic: Automotive Grade

7.Connection Type: Wifi
