Car sensor tester Bluetooth OBDII auto scanner ELM327 KW902
diagnostic tool with 25K80 chip
KW902 description:
The device is a small adapter that plugged into the vehicle OBDII
connector via bluetooth, it is suitable for android smart devices
or Windows PC.
With associated diagnostic procedures, Free obd software provided
in the package ).
With this product, you will be able to perform a complete computer
diagnostic car and even correct minor faults without resorting to
service stations.
Main features:
Display real-time performance of your car, such as momentum,
vehicle speed, oil pressure, coolant temperature, engine load,
intake manifold pressure, throttle position and air intake
temperature.
If the communication is terminated, this item will automatically
switch to sleep mode in half an hour.
The adapter adopts fast and reliable chips which promise its stable
wireless connection.
It supports all OBDII protocols: J1850 VPW, J1850 PWM, IS09141 - 2,
KWP2000 and CAN
Small size and compact structure, plug and play.
Key parameters:
| Brand | KONNWEI |
| Product name | KW902 ELM 327 BT wireless scanner |
| Chip | 25K80 |
| Language | English defaulted and can select the language you need |
| Main Function | precisely analyze and display vehicle performance |
| Feature | For all 12V cars OBD2 certified |
| Connection Type | BT wireless 3.0 |
| Auxiliary phone software | Torque |
| color | Five colors for choice |
| Warranty | 12 mouths |
Supports protocol and language:
| 0)Automatic |
| 1) ISO9141-2(5 baud init,10.4Kbaud) |
| 2) ISO14230-4 KWP(5 baud init,10.4Kbaud) |
| 3) ISO14230-4 KWP(fast init,10.4Kbaud) |
| 4) ISO15765-4CAN(11bit ID,500 Kbaud) |
| 5) ISO15765-4CAN(29bit ID,500 Kbaud) |
| 6) ISO15765-4CAN(11bit ID,250 Kbaud) |
| 7) ISO15765-4CAN(29bit ID,250 Kbaud) |
| 8) SAE J1850 PWM (41.6 Kbaud) |
| 9) SAE J1850 VPW (10.4 Kbaud) |
| 10)default settings(user adjustable) |
This software support a lot of languages, like Russian, Spanish,
French, German, English, Italian, Portuguese...etc.
( you can download the app: For Torque, to see whether it includes
your country language.)
Package includes:
1 * KW902
1 * User's manual
1 * CD
KW902 detail pictures :
Recommended Product:
| IC chip | STM32F103VCT6 |
| Main function | Read and erase all BOD2 engine fault codes |
| Display Mode | 2.8 inch TFT HD color screen(320 x 240 dpi), built-in speaker |
| Feature | upgrade system online lifetime free print data |
| Language | Support 8 languages |
| Support System | XP WIN7 WIN8 WIN10 |
| OEM/ODM | Welcome, please contact me |
| color | Black & Red optional |
